2019 Land Pride FDR1672 Mowers 186365

FDR1672-72 Finishg Mower-3PT

Model Number: FDR1672

Recommended Tractor Horsepower: 15–40 HP (11.2–29.8 kW)
Cutting Width: 72 in (1.83 m)
Overall Width: 74.5 in (1.89 m)
Height: 36 in (0.91 m)
Length: 72 in (1.83 m)
Weight: 619 lbs (280.8 kg)
Deck Material Thickness: 3/16 in (5 mm)
Blade Tip Speed: 18,130 fpm (92.1 m/s)
Blade Construction (3 total): 1/4 in x 2.5 in x 25 in heat-treated alloy steel
Blade Options: Standard (Medium Lift), with optional Low Lift, High Lift, and Mulching blades
Blade Overlap: 1.25 in (3.2 cm)
Blade Spindles: 1-3/8 in diameter, cast iron greasable hubs
Cutting Height: Adjustable from 3/4 in to 5-1/4 in (19 mm – 133 mm) in 1/2 in increments
Hitch: Category I, floating 3-point hitch with floating clevis/hitch pins
Discharge: Rear discharge design
Drivetrain: 540 RPM PTO, cast-iron gearbox with beveled gears, 1:2.83 ratio, spring-loaded single V-belt
Gearbox Oil Capacity and Type: 2.5 pints of 80-90W EP gear lube
Drive Line: Heavy-duty with quick coupler, ASAE Cat. 2 driveline
Castered Gauge Wheels: 3.25 in x 10 in solid rubber tires; 1 in diameter spindle with nylon bushing
Deck Design: Roll-formed front edge with frame-over-deck construction for durability; non-aligned rear gauge wheels minimize grass laying over
Quick Hitch Compatibility: Yes, compatible with Land Pride Quick Hitch system

Notes:

• Designed for smooth, high-quality turf and lawn finishing.

• Ideal for compact and utility tractors up to 40 HP.

• Durable construction and replaceable blades for long service life.

• Rear discharge evenly disperses clippings for a professional finish.
