NEW Bandit 19XPC Chipper-Hand Fed-19" Drum-Cat 174Hp-Yellow

Chipper-Hand Fed-19" Drum-Cat 174Hp-Yellow

Chipping & Feed System

• Material Capacity: 19 in

• Drum Size: 37 in diameter × 22 in wide

• Knives: 4-knife drum

• Throat Opening: 20.5 in × 20.88 in

• Feed Wheels: Dual horizontal feed wheels (top + bottom)

• Top Feed Wheel Size: 15.75 in diameter × 25 in wide

• Bottom Feed Wheel Size: 10.625 in diameter × 25 in wide

• Pulling Force: Approx. 10,824 lbs

• Feed Rate: Approx. 100 ft/min

• Infeed Hopper: 33.75 in high × 64 in wide (with folding tray)

Engine & Power

• Engine: CAT diesel

• Horsepower: 174 hp

• Fuel Tank: 30 gal

• Hydraulic Tank: 30 gal

Dimensions & Weight

• Overall Length: 249 in

• Overall Width: 93 in

• Overall Height: 110 in

• Weight: Approx. 10,500 lbs

Discharge & Features

• Discharge Chute: 360° swivel with adjustable deflector

• Feed System Type: Slide-box feed system

• Feed Assistance: Hydraulic lift cylinder for additional down-pressure

• Safety Features: Infeed safety bar, auto-reversing feed, rope/line sheer device

• Optional Upgrades: Hydraulic winch, heavy-duty infeed tray, wider feed wheels, tandem axle or track undercarriage
