CTL-Gold Package-Hand Foot-Narrow Pad-Zig Zag
Engine & Power
Engine: Kubota V2003T, 4-cylinder, turbocharged diesel
Horsepower (gross): 66 hp @ ~2700–2800 rpm
Horsepower (net): approx. 61 hp @ 2700 rpm
Displacement: 122 cu in (2.0 L)
Fuel Capacity: 28 gal
Operating Specs
Rated Operating Capacity (35% ROC): 1,900 lb
Operating Capacity (50% of tipping): approx. 3,400 lb
Tipping Load: approx. 5,430 lb
Operating Weight: approx. 7,244 lb (up to ~7,700 lb with cab/options)
Travel Speed (high range): approx. 7.0–7.1 mph
Hydraulic System
Standard Auxiliary Flow: approx. 16.7 gpm
High-Flow (if equipped): approx. 27 gpm
System Relief Pressure: approx. 3,300 psi
Tracks & Undercarriage
Track Width (narrow): 12.6 in rubber tracks
Track Pattern: Zig-zag tread
Ground Pressure: approx. 5.0 psi
Ground Contact Length: approx. 55.2 in
Dimensions
Length with Bucket: 130.3 in
Length without Attachment: 101.9 in
Width over Tracks: approx. 66.0 in
Width with 68" Bucket: 68.0 in
Height to Top of Cab: 76.3 in
Operating Height (bucket fully raised): 152.1 in
Ground Clearance: 8.1 in
Angle of Departure: 30°
Included Configuration Details
Package: Gold Package (dealer option package; contents may vary)
Controls: Hand & foot mechanical controls
Tracks: Narrow rubber tracks with zig-zag tread pattern
| Brand | Bobcat |
| Condition | Used |
| Model | T190 |
| Year | 2001 |
