2005 Kubota L4610D Tractors 245796

Tractor-4WD-HST-Cab

Engine:

• Kubota E-TVCS V2203 4-cylinder diesel, liquid-cooled

• Displacement: 2.2 L (134.1 cu in)

• Gross Power: 47.8 hp (35.6 kW)

• Net Power: 46 hp (34.3 kW)

• Bore x Stroke: 87 mm x 92 mm (3.43 in x 3.64 in)

• Fuel Capacity: 9.2 gallons (34.8 L)

Transmission:

• Hydrostatic Transmission (HST)

Drive & Chassis:

• 4WD / MFWD

• Power steering (hydrostatic)

• Wet disc brakes

• 2-post ROPS (cab optional)

Hydraulics:

• Open-center hydraulic system

• Pump Flow: 9.6 gpm (36.3 L/min)

• Total Flow: 14.4 gpm (54.5 L/min)

• Steering Flow: 4.8 gpm (18.2 L/min)

3-Point Hitch:

• Category 1

• Position control (optional draft control)

• Rear Lift Capacity (at 24 in): 2,310 lb (1,047 kg)

PTO (Power Take-Off):

• Independent rear PTO

• PTO Type: 540 rpm, 1.375-inch shaft

• PTO Power (Gear): 40.5 hp (30.2 kW)

• PTO Power (Hydro): 39 hp (29.1 kW)

Dimensions:

• Wheelbase: 71.5 in (181 cm)

• Overall Length: 117.5 in (298 cm)

• Overall Width: 62.4 in (158 cm)

• Height (ROPS): 84.8 in (215 cm)

• Height (Cab): 86.8 in (220 cm)

• Ground Clearance: 15 in (38 cm)

Weights (Approximate):

• ROPS GST: 3,180 lb (1,442 kg)

• ROPS Hydro: 3,200 lb (1,451 kg)

• Cab Hydro: 3,650 lb (1,655 kg)

Tires:

• Front: 8.3-16

• Rear: 14.9-24

Electrical:

• Alternator: 40 amps (ROPS) / 55 amps (Cab)

• Battery: 12V, 582 CCA
