2015 Kubota SVL90-2HC Compact Track Loaders 119540

CTL-A/C Cab/Heat-Hyd QC-18 Track

• Model: Kubota SVL90-2HC

• Type: Compact Track Loader / Multi-Terrain Loader

Engine

• Engine Manufacturer: Kubota

• Engine Model: V3800-CR-T (Turbocharged diesel)

• Gross Horsepower: Approx. 92 hp

• Number of Cylinders: 4

• Displacement: ~230 cu in (3.8 L)

Performance

• Operating Weight: Approx. 11,299 lb

• Rated Operating Capacity (35% tipping load): Approx. 3,010 lb

• Rated Operating Capacity (50% tipping load): Approx. 4,300 lb

• Tipping Load: Approx. 8,598 lb

• Bucket Breakout Force: Approx. 7,961 lb

• Traction Force: ~12,178 lb

• Ground Pressure: Approx. 4.2–4.3 psi

Hydraulics

• Hydraulic System Flow (Standard): ~25.1 gpm

• Hydraulic System Flow (High Flow, if equipped): Up to ~36.5 gpm

• Hydraulic Relief Pressure: ~3,555 psi

• Hydraulic Tank Capacity: ~10.1 gal

• Hydraulic System Fluid Capacity: ~18.0 gal

Transmission & Travel

• Travel Speed – Low: ~5.0 mph

• Travel Speed – High: ~7.3 mph

• Traction Type: Vertical lift arm path

Fuel & Capacities

• Fuel Type: Diesel

• Fuel Tank Capacity: ~29.9–30.0 gal

Dimensions

• Overall Width: Approx. 77.2 in

• Overall Length (with bucket): Approx. 148 in

• Height to Top of Cab: ~83.4 in

• Length of Track on Ground: ~65.6 in

• Ground Clearance: ~11.8 in
