NEW Land Pride STB1072 Snow Trip Blade-72 -Hyd Angle-Fit 25-40 hp Tractor

Snow Trip Blade-72 -Hyd Angle-Fit 25-40 hp Tractor

Land Pride STB1072 Snow Trip Blade Specs (72")

Model: STB1072
Series: STB10 Series Snow Trip Blade
Type: Loader-Mounted Trip Snow Blade (Hydraulic Angle)
Application: Snow removal, light grading, and surface clearing for driveways, parking areas, and small properties
Compatibility: Tractor loaders 25–40 HP

Dimensions & Weight

• Blade Width (Max Cutting Width): 72 in
• Cutting Width @ 30° Angle: ~62 in
• Moldboard Height: ~22 in
• Moldboard Thickness: 12-gauge steel
• Approximate Weight: ~390–403 lb (steel vs poly cutting edge)

Blade Performance & Movement

• Hydraulic angle range: 30° left / 30° right
• Double-acting hydraulic angling cylinder
• Trip-edge design with spring trip protection
• Trip release force: ~600 lb
• Cushion valve protection for shock loads

Cutting Edge & Ground Contact

• Replaceable and reversible cutting edge
• 1/2" x 6" steel or poly edge options
• AR400 skid shoes for wear resistance
• Adjustable skid shoes to control cutting depth
• Designed to protect paved or gravel surfaces

Hydraulic System

• 2" bore x 6" stroke angle cylinder
• Maximum hydraulic pressure: up to 3000 psi
• Loader quick-attach hydraulic operation required
• Smooth angling for windrowing snow or debris

Mounting & Compatibility

• Universal skid steer quick attach (SSQA)
• Front loader mounted system
• Fits compact tractors with loaders
• Designed for Kubota B, LX, and L series compatibility

Construction Features

• Heavy-duty 12-gauge reinforced moldboard
• Structural reinforcement for loader-mounted use
• High-visibility blade markers for edge awareness
• Durable powder-coated finish
• Built for snow and light material handling

Performance Features

• Trip-edge absorbs impacts from hidden obstacles
• Excellent for snow removal on uneven surfaces
• Hydraulic angle allows windrowing to either side
• Skid shoes help maintain consistent scraping height
• Optional rubber deflector reduces snow roll-over

Common Uses

• Driveway snow removal
• Parking lot clearing
• Light grading and leveling
• Farm lane maintenance
• Commercial lot snow management
• Gravel or paved surface clearing

Key Features

• 72" maximum width
• ~62" angled cutting width
• 25–40 HP tractor compatibility
• Hydraulic left/right angle (30° each way)
• Trip-edge spring protection system
• Replaceable steel or poly cutting edge
• AR400 skid shoes
• Universal SSQA mounting
• Approx. 390–403 lb operating weight

Quick Takeaway

The Land Pride STB1072 is a 72-inch hydraulic trip blade designed for compact tractors in the 25–40 HP range. Its spring-trip edge, hydraulic angling, AR400 skid shoes, and replaceable cutting edge make it a versatile tool for snow removal and light grading on driveways, parking areas, and farm properties.
