NEW Land Pride STB1596 Snow Trip Blade-96 -Hyd Angle-Fit 30-70 hp Tractor

Snow Trip Blade-96 -Hyd Angle-Fit 30-70 hp Tractor

Land Pride STB1596 Snow Trip Blade Specs (96")

Model: STB1596
Series: STB15 Series Snow Trip Blade
Type: Loader-Mounted Hydraulic Trip Blade (Snow & Light Material)
Application: Snow removal, light grading, and surface clearing for driveways, parking lots, farms, and commercial properties
Compatibility: Compact & utility tractors 30–70 HP

Dimensions & Weight

• Blade Width (Straight): 96 in (8 ft)
• Cutting Width @ 30° Angle: ~83 in
• Moldboard Height: 27 in
• Moldboard Type: Curved heavy-duty steel moldboard
• Approximate Weight: ~690–740 lb (varies by edge type and configuration)

Blade Movement & Performance

• Hydraulic angle: 30° left / 30° right
• Dual hydraulic angle cylinders
• Trip-edge spring protection system
• Heavy-duty trip mechanism designed to absorb impacts from hidden obstacles
• Side float capability for contour following

Trip System

• Dual trip springs for shock absorption
• Trip-edge design helps protect tractor and blade from damage
• Resettable after obstacle impact
• Built for snowbanks, curbs, and uneven surfaces

Cutting Edge & Ground Contact

• Replaceable and reversible cutting edge
• Steel or poly cutting edge options
• AR400 skid shoes for wear resistance
• Adjustable skid shoes for depth control
• Designed for both paved and gravel surfaces

Hydraulic System

• Requires loader auxiliary hydraulics
• Hydraulic cylinder(s) for angling
• Smooth angle control for windrowing snow or material
• Designed for use with skid steer quick attach systems

Mounting & Compatibility

• Universal Skid Steer Quick Attach (SSQA)
• Front loader mounted configuration
• Compatible with compact and utility tractors (Kubota L, MX, M series and similar)

Construction Features

• Heavy-duty welded steel frame
• Reinforced 10–12 gauge structural steel components
• High-visibility blade markers
• Durable powder-coated finish
• Built for commercial-grade durability

Performance Features

• Excellent for large-area snow removal
• Hydraulic angling improves windrowing efficiency
• Trip-edge reduces damage risk on hidden obstacles
• Wide 96" blade reduces number of passes required
• Effective for snow, light dirt, and loose material pushing

Common Uses

• Large driveway snow removal
• Parking lot clearing
• Farm lane maintenance
• Light grading and leveling
• Commercial snow management
• Municipal maintenance applications

Key Features

• 96" working width
• ~83" angled cutting width
• 30–70 HP tractor compatibility
• Hydraulic 30° left/right angling
• Dual trip spring protection system
• Curved heavy-duty moldboard
• AR400 skid shoes
• Replaceable cutting edge
• Universal SSQA mounting
• Approx. 690–740 lb operating weight

Quick Takeaway

The Land Pride STB1596 is a 96-inch hydraulic trip blade designed for 30–70 HP tractors. With dual hydraulic angling cylinders, a rugged trip-edge spring system, and a heavy-duty curved moldboard, it delivers high-capacity snow removal and light grading performance for large driveways, commercial lots, and agricultural applications.
